Installation and Setup
Loading the Laminate
P1013372-001 Rev. A Zebra ZXP Series 8 Card Printer with Laminator 27
Laminating Contact Smart Cards
The laminate for the top surface of a contact smart card has a repeating pattern of an index hole
and a rectangular cutout to expose the card’s electrical contacts.
Step 1. Remove the Upper Laminate Cassette; see Page 20 .
Step 2. Open the cassette, and remove the laminate if present.
Step 3. Load the smart card laminate into the cassette; see Page 22 .
Step 4. Cut the laminate, splitting the index hole as shown.
electrical contacts
index hole
rectangular cutout
Cut the laminate, splitting the
index hole
