206 Zebra ZXP Series 8 Card Printer with Laminator P1013372-001 Rev. A
Packing the Printer for Shipment
Step 7. Open the laminator Door.
Step 8. Remove the Laminate Cassette(s). If you wish to save the laminate for future use,
you may want to put the cassette(s) in a plastic bag for storage.
Step 9. Close the laminator Door.
Step 10. Remove the Input and Output Hopper, and place them in the foam insert.
Step 11. Place the Printer in its protective plastic bag.
Step 12. Place the lower foam insert in the Shipping Carton.
Step 13. Attach the carrying strap around the Printer in the following order:
a. Place loop #1 around the rear of the Printer.
b. Place loop #2 around the Laminator.
c. Place loop #3 around the Card Input and OCP Assembly.
Note • In the following two illustrations, the protective plastic bag has been omitted for
clarity. Note that the strap loops have been colored (blue, green, and red) for clarity.
1
2
3
