Setting Custom Card Specifications
Adjustments
P1013372-001 Rev. A Zebra ZXP Series 8 Card Printer with Laminator 171
B.4.6 Special Cases
Flash on Smart Card Chip
Step 1. Decrease Front Transfer Temperature:
a. Go to the Card Specifications window; see Section B.3 .
b. Make a note of the default front transfer temperature settings.
c. Decrease the appropriate (single or double side) front transfer temperature by 5.
d. Click on the OK button.
e. Print a test card.
f. Examine the test card; see Section B.3 .
• If there is noticeable improvement, continue decreasing the front transfer
temperature by 5, printing a test card, and examining the resulting card. Stop
when the problem is corrected or there is no more improvement. If the
problem is corrected, no more adjustment is required; otherwise go to
Step 2 .
• If there is no noticeable improvement, return the temperature to its default
setting; and go to Step 2 .
