134 Zebra ZXP Series 8 Card Printer with Laminator P1013372-001 Rev. A
Technical Specifications
Specifications
Electrical
• Auto-switching Single-phase AC power
• 90V~264V AC RMS and 47-63 HZ (50-60 Hz nominal)
• Power consumption:
Idle 160 W
Printing 340 W
Initializing / Warm-up 570 W
Sleep 20 W
Physical
• Height 11.62" (295 mm)
• Width 25.2" (640 mm)
• Depth 20.82" (529 mm)
• Weight 44 lbs (20 kg)
Environmental
• Operating Temperature 59º to 77ºF (15º to 25ºC)
• Storage Temperature 23º to 131ºF (-5º to 55ºC)
• Operating Humidity 20% to 80% non-condensing
• Storage Humidity 10% to 90% non-condensing
• Shipping Temperature -40º to 140ºF (-40º to 60ºC)
• Shipping Humidity 10 to 90% non-condensing
Note • Osprey printer setup temperature for composite card top @ 175C & bottom @ 180C,
then laminator setup for both sides lamination @ 140C. Power with 120VAC 60HZ.
