3 - 5 2 DocuTech 128/155/180 HighLight Color Operator Guide
Routine maintenance
Figure 3-50 Cleaning the calipers
Closing the binder
NOTE: Production publisher configuration only
Perform the following steps to close the binder.
1. Push in the binder drawer until it stops.
2. Close the finisher doors.
3. Place the platen cleaner in a safe place.
Replacing the stitcher spool A
NOTE: Production publisher configuration only
Use this procedure to replace stitcher spool A in the system.
Check stitcher spools A and B visually during the warm-up cycle.
Stitcher spool A is the spool on top, and stitcher spool B is the
spool on the bottom.
If spool B needs new wire, call the customer support center.
There is a label behind the stitcher panel that gives instructions for
replacing the stitcher spool A. Refer to this label if needed.
The following steps must be performed to replace the stitcher
spool A.
