DocuTech 128/155/180 HighLight Color Operator Guide 3- 11
Routine maintenance
Adjusting the decurler lever
Perform the following steps to adjust the decurler lever.
CAUTION: Do not use any paper that is not suitable for system
use.
1. Open the right door of the processor.
2. Locate the decurler lever in area 7 of the paper path, as shown
in the figure below.
Figure 3-7 Locating the decurler lever
3. If the print curl is +2 or more, move the green decurler lever to
the right.
4. If the print curl is -3 or more, move the green decurler lever to
the left.
5. If the decurler adjustment does not eliminate the paper curl
problem, or for other curl problems, turn the stack of paper
over in the paper tray.
6. If there is still a curl problem, perform steps 1 to 4 again.
NOTE: A final solution to the curl problem may be to load a
new ream of paper.
7. Close the processor door.
