DocuTech 128/155/180 HighLight Color Operator Guide 5- 15
Technical information
Set or stack
size Substance 16 to 20 (60 to
75 g/m2) Over substance 20 (75 g/
m2) stock as sets or stacks
increases the likelihood of
bindexer jams. When using copy paper
heavier than substance 20 (75
g/m2), limit the stack or set
size by dividing the set into
parts. Combine prints when
completed and finish offline, if
required. For collated
unfinished sets, the maximum
sheet capacity of the bindexer
can be set to between 50 and
125.
Stacker
capacity Unfinished sheets:
3300 sheets, substance
16 (60 g/m2)
3000 sheets, substance
20 (75 g/m2)
2500 sheets, substance
24 (90 g/m2)
1875 sheets, substance
32 (120 g/m2)
1360 sheets, substance
110 (200 g/m2) To allow a continuous run,
unload outer stack before
inner stack reaches capacity.
Type or
condition Xerographic bond paper in
good condition
Drilled paper Slightly curled paper Do not use excessively curled
paper.
Transparencies must contain
some opaque sheets to avoid
finisher jams.
Stock not defined here is
included in the “Using various
stocks” section in this guide.
Table 5-11. Stitcher satisfaction guide
Stock Reliable stacking may be
expected Less reliable stacking may
be expected Suggested alternatives
Size 8 x 10 inches to 9 x 14
inches (203 x 254 mm to
229 x 356 mm) Use the top tray for larger
sizes
Weight Substance 16 to 110 (60 to
200 g/m2) Weights outside the limits
shown are not recommended.
Set size limit
due to copy
paper weight Collated: Up to 65 sheets
of substance 20 (75 g/m2)
or 0.28 inch (7 mm) thick
sets
Uncollated: 50 copies
maximum per stitch 0.28
inch (7 mm) thick sets Collated: Up to 70 sheets of
substance 20 (75 g/m2) Reduce the paper weight to
enable stitching more sheets
per collated set.
Check the stitch quality.
Stacker
capacity Stacker capacity adjusts
automatically to suit
various set sizes To allow a continuous run,
unload outer stack before
inner stack reaches capacity.
Stock
Reliable stacking may be
expected Less reliable stacking may
be expected
Suggested alternatives
