DocuTech 128/155/180 HighLight Color Operator Guide 5- 17
Technical information
Set size limits Maximum collated:
125 sheets of substance
20 (75 g/m2) or equivalent
thickness
Minimum collated:
15 sheets of substance 20
(75 g/m2) (7 sheets with
index covers) or
equivalent thickness
Maximum uncollated:
100 sheets of substance
20 (75 g/m2)
Minimum uncollated:
15 sheets of substance 20
(75 g/m2) (7 sheets with
index covers) or
equivalent thickness 125 sheets of substance 16
(60 g/m2) Consider stitching for set sizes
smaller than 15 sheets (or
equivalent thickness).
Reduce the number of sheets
to maintain a maximum set
thickness of 0.5 inch (13 mm)
when using heavier than
substance 20 (75 g/m2) for
main body or inserts.
Stacker
capacity Delivers 12 sets inboard
and 12 sets outboard To allow continuous run,
unload outer stack before
inner stack reaches capacity.
Type or
condition Xerographic bond paper in
good condition
Drilled paper Slightly curled paper Avoid the following:
Coated papers
Drilled stock with reinforced
edges
Transparencies as inserts
Excessively curled paper
Never-tear paper
Stock not defined here is
included in the “Using various
stocks” section in this guide.
Table 5-13. Top tray satisfaction guide
Stock Reliable stacking may be
expected Less reliable stacking may
be expected Suggested alternatives
Size 8 x 10 inches to 11 x 17
inches (203 x 254 mm to
279 x 432 mm) Intermixed sizes Smaller or larger sizes cannot
be used.
Weights Substance 16 to 110 (60 to
200 g/m2)
Weights cannot be
intermixed Substance 16 (60 g/m2)
over 9 x 14 inches (229 x
356 mm) may yield stacking
registration problems. Weights outside the limits
shown are not recommended.
Capacity 500 sheets, substance 20
(75 g/m2) or less
415 sheets, substance 24
(90 g/m2)
310 sheets, substance 32
(120 g/m2)
225 sheets, substance 110
(200 g/m2) If using a paper heavier than
substance 20 (75 g/m2),
unload the tray before the
count in the tray reaches 500.
Check the stitch quality.
Table 5-12. Binder satisfaction guide
Stock Reliable stacking may be
expected Less reliable stacking may
be expected Suggested alternatives
