2 - 2 0

DocuTech 128/155/180 HighLight Color Operator Guide

System components

4. High-capacity feeder tray 4

a. Side 1 of sheet leaving feeder tray

b. Drilled holes (on right edge)

c. Origin 0,0: portrait orientation

5. Paper inverter

6. Duplex inverter

7. Sample tray

8. High-capacity stacker bin A

a. Side 2 of sheet stacked in bin

b. Drilled holes (on left edge)

c. Origin 0,0: portrait orientation

9. High-capacity stacker bin B

a. Side 2 of sheet stacked in bin

b. Drilled holes (on left edge)

c. Origin 0,0: portrait orientation

10. Purge tray

11. Bypass transport

a. Side 2 of sheet passing through bypass transport

b. Drilled holes (on left edge)

c. Origin 0,0: portrait orientation
