Technical information
displayed on the DocuSP controller to warn the Print Services
Operator that the paper stock to be rotated will not fit in the
Bypass Transport.
The Signature Booklet Maker attached to a DocuTech 128/155/
180 HLC printer is only capable of handling paper stock up to 9
inches (229 mm) in length in a portrait orientation.
With the introduction of other DFA-complaint finishing devices for
use with the DocuTech 128/155/180 HLC family of printers,
additional paper stock sizes can be handled by the finishing
devices, both straight from the Bypass Transport or rotated.
Limitations
Do not rotate paper sizes that will not fit through the DocuTech
128/155/180 HLC Bypass Transport to a third party finishing
device.
Before creating a document to be rotated by the Bypass
Transport, set the paper stock size required to fit within the
limitations detailed in the following tables and as follows:
• The diagonal dimension of the paper stock must be equal to or
less than 18 inches (457 mm).
• The paper stock must be within the paper stock size
parameters of the DocuTech 128/155/180 HLC printer paper
trays.
Refer to the DocuSP controller on-line help system for information
on setting finisher devices and finisher profiles to enable rotation
to a third party finisher.
Table 5-8. Common US paper sizes
Common
size name
Inches x
inches
Millimeter
equivalent
Diagonal in inches
Can be
rotated
Comment
(similar to or the
same as)
8.0 x 10.75 203 x 273 13.40 YES
US Letter/ US
A-size 8.5 x 11.0 216 x 279 13.90 YES 2-up of US 5.5 x
8.5 in.
(statement)
9.0 x 12.0 229 x 305 15.00 YES 2-up of US 6.0 x
9.0 in. (common
“book” size)
US Legal 8.5 x 14.0 216 x 356 16.38 YES ISO Foolscap
9.0 x 14.0 229 x 356 16.64 YES 2-up of US 7.0 x
9.0 in.
9.0 x 15.0 229 x 381 17.49 NO* 2-up of US 7.5 x
9.0 in.
