270
MIDI Implementation
Model: XV-88 (128-Voice Expandable Synthesizer)
Date: Feb. 15, 2000
Version: 1.00
1. Receive data
■ Channel Voice Messages
* Not received in Performance mode when the Rx Sw parameter (PERFORM/MIDI/
MIDI) is OFF.
● Note off
Status 2nd byte 3rd byte
8nH kkH vvH
9nH kkH 00H
n = MIDI channel number: 0H - FH (ch.1 - 16)
kk = note number: 00H - 7FH (0 - 127)
vv = note off velocity: 00H - 7FH (0 - 127)
* Not received when the Envelope Mode parameter (PATCH/CONTROL/CTRL RxMIDI
and RHYTHM/CONTROL/CONTROL) is NO-SUS.
● Note on
Status 2nd byte 3rd byte
9nH kkH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
kk = note number: 00H - 7FH (0 - 127)
vv = note on velocity: 01H - 7FH (1 - 127)
● Polyphonic Key Pressure
Status 2nd byte 3rd byte
AnH kkH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
kk = note number: 00H - 7FH (0 - 127)
vv = Polyphonic Key Pressure: 00H - 7FH (0 - 127)
* Not received in Performance mode when the Paf parameter (PERFORM/MIDI/
RxSWITCH) is OFF.
● Control Change
* If the corresponding Controller number is selected for the Control 1, 2, 3 or 4 parameter
(PATCH/CONTROL/MATRIX CTRL SRC), the corresponding effect will occur.
* If a Controller number that corresponds to the Control 1, 2, 3 or 4 parameter (SYSTEM/
CONTROL/SYS CTRL ASSIGN 1, 2, 3, 4) is selected, the specified effect will apply if
Control 1, 2, 3 or 4 parameter (PATCH/CONTROL/MATRIX CTRL SRC) is set to SYS-
CTRL1, SYS-CTRL2, SYS-CTRL3 or SYS-CTRL4.
❍ Bank Select (Controller number 0, 32)
Status 2nd byte 3rd byte
BnH 00H mmH
BnH 20H llH
n = MIDI channel number: 0H - FH (ch.1 - 16)
mm, ll = Bank number: 00 00H - 7F 7FH (bank.1 - bank.16384)
* Not received in Performance mode when the BankSelect (PERFORM/MIDI/
RxSWITCH) is OFF.
* The Performances, Rhythms, and Patches corresponding to each Bank Select are as
follows.
* The SRX series corresponding to each Bank Select are to see the SRX series owner's
manual.
BANK SELECT | PROGRAM | GROUP | NUMBER
MSB | LSB | NUMBER | |
—————+———————————+———————————+——————————————————————+———————————
000 | | 001 - 128 | GM Patch |
: | | | |
032 | | 001 - 128 | GM Patch |
085 | 000 | 001 - 064 | User Performance | 001 - 064
| 032 | 001 - 064 | Card Performance A | 001 - 064
| 033 | 001 - 064 | Card Performance B | 001 - 064
| : | | : |
| 064 | 001 - 032 | Preset Performance A | 001 - 032
| 065 | 001 - 032 | Preset Performance B | 001 - 032
| : | | : |
086 | 000 | 001 - 004 | User Rhythm | 001 - 004
| 032 | 001 - 004 | Card Rhythm A | 001 - 004
| 033 | 001 - 004 | Card Rhythm B | 001 - 004
| : | | : |
| 064 | 001 - 002 | Preset Rhythm A | 001 - 002
| 065 | 001 - 002 | Preset Rhythm B | 001 - 002
| : | | : |
087 | 000 | 001 - 128 | User Patch | 001 - 128
| 032 | 001 - 128 | Card Patch A | 001 - 128
| 033 | 001 - 128 | Card Patch B | 001 - 128
| : | | : |
| 064 | 001 - 128 | Preset Patch A | 001 - 128
| 065 | 001 - 128 | Preset Patch B | 001 - 128
| : | | : |
088 | 000 - 001 | 001 - 128 | SR-JV80-01 Rhythm | 001 - 256
| 002 - 003 | 001 - 128 | SR-JV80-02 Rhythm | 001 - 256
| : | | : |
089 | 000 - 001 | 001 - 128 | SR-JV80-01 Patch | 001 - 256
| 002 - 003 | 001 - 128 | SR-JV80-02 Patch | 001 - 256
| : | | : |
092 | 000 - | 001 - | SRX Rhythm | 001 -
| : | | : |
093 | 000 - | 001 - | SRX Patch | 001 -
| : | | : |
120 | | 001 - 057 | GM Rhythm | 001 - 009
121 | 000 - 009 | 001 - 128 | GM Patch | 001 - 256
❍ Modulation (Controller number 1)
Status 2nd byte 3rd byte
BnH 01H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Modulation depth: 00H - 7FH (0 - 127)
* Not received in Performance mode when the Mod parameter (PERFORM/MIDI/
RxSWITCH) is OFF.
❍ Breath type (Controller number 2)
Status 2nd byte 3rd byte
BnH 02H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
❍ Foot type (Controller number 4)
Status 2nd byte 3rd byte
BnH 04H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
❍ Portamento Time (Controller number 5)
Status 2nd byte 3rd byte
BnH 05H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Portamento Time: 00H - 7FH (0 - 127)
* In Performance mode the Portament Tm parameter (PERFORM/PART/MONO/POL)
will change.
❍ Data Entry (Controller number 6, 38)
Status 2nd byte 3rd byte
BnH 06H mmH
BnH 26H llH
n = MIDI channel number: 0H - FH (ch.1 - 16)
mm, ll = the value of the parameter specified by RPN/NRPN
mm = MSB, ll = LSB
