129
Chapter 7. Adding Effects
Chapter 7
19: TRIPLE TAP DELAY
The Triple Tap Delay produces three delay sounds; center,
left and right.
fig.MFX-19
Delay C (Delay Time Center)
Adjust the time delay from the direct sound until when the
center delay sound is heard.
Delay L (Delay Time Left)
Adjust the time delay from the direct sound until when the
left delay sound is heard.
Delay R (Delay Time Right)
Adjust the time delay from the direct sound until when the
right delay sound is heard.
Delay C, Delay L and Delay R parameters can be set as a
note-value of a specified tempo. In this case, specify the
value of the desired note.
Fbk (Feedback Level) #
Adjust the proportion (%) of the delay sound that is fed back
into the effect. Negative (-) settings will invert the phase.
Level C (Center Level)
Adjust the volume of the center delay sound.
Level L (Left Level)
Adjust the volume of the left delay sound.
Level R (Right Level)
Adjust the volume of the right delay sound.
HF Damp
Adjust the frequency above which sound fed back to the
effect will be cut. If you do not want to cut the high
frequencies of the feedback, set this parameter to BYPASS.
LowGain (Low Gain)
Adjust the gain of the low frequency range.
Hi Gain (High Gain)
Adjust the gain of the high frequency range.
Balance (Effect Balance) #
Adjust the volume balance between the direct sound and the
delay sound. With a setting of D100:0W only the direct sound
will be output, and with a setting of D0:100W only the delay
sound will be output.
Level (Output Level)
Adjust the output level.
L in
R in
L out
R out
Left Tap
Right Tap
Triple Tap Delay
2-Band
EQ
2-Band
EQ
Balance W
Balance D
Balance W
Balance D
Feedback
Center Tap
When Delay C, Delay L and Delay R are Set
as a Note Value
As the specified tempo, you may use either the Patch
Tempo (p. 71) or the tempo clock of the XV-88’s system
(p. 169).
