224
Quick Reference of Procedures
Controlling Tone
Parameters of the Patch
by the Slider or Pedal
(Matrix Controller) For each Patch, you can specify up to four control sources
(MIDI messages for controlling). For each control source, you
can specify up to four control destinations (parameters to be
controlled).
1. Specify the MIDI messages to be controlled by each
controller (the C1–C4 slider, control pedal etc.) (see
previous).
2. Choose a control source (MIDI messages used for control).
Control 1–4 parameters (PATCH/CONTROL/MATRIX
CTRL SRC)
* If you do not need to set different control sources for each Patch,
select SYS-CTRL 1–4, and use the Control 1–4 parameters
(SYSTEM/CONTROL/SYS CTRL ASSIGN 1–4) to choose the
MIDI messages that you wish to use for control.
3. Specify the control destination (the parameter to be
controlled).
Dest parameter (PATCH/CONTROL/MATRIX
CONTROL 1–4)
4. Set the Control Sensitivity (the amount of the effect that is
applied).
Sns parameter (PATCH/CONTROL/MATRIX
CONTROL 1–4)
5. Select the Control Tone (the Tone to which the effect is
applied).
Tone parameter (PATCH/CONTROL/MATRIX
CONTROL 1–4)
