150
Chapter 7. Adding Effects
55: STEREO COMPRESSOR
fig.MFX-55
Sustain
Adjust the time over which low level sounds are boosted
until they reach the specified volume.
Attack (Attack Time)
Adjust the attack time of an input sound.
Post Gain
Adjust the output gain.
LowGain (Low Gain)
Adjust the low frequency gain.
Hi Gain (High Gain)
Adjust the high frequency gain.
Level (Output Level) #
Adjust the output level.
56: STEREO LIMITER
fig.MFX-56
Thre (Threshold Level)
Adjust the volume at which compression will begin.
Release (Release Time)
Adjust the time from when the volume falls below the
Threshold Level until compression is no longer applied.
Ratio (Compression Ratio)
Adjust the compression ratio.
Gain (Post Gain)
Adjust the output gain.
LowGain (Low Gain)
Adjust the low frequency gain.
Hi Gain (High Gain)
Adjust the high frequency gain.
Level (Output Level) #
Adjust the output level.
L in
R in
L out
R out
Compressor
2-Band EQ
2-Band EQ
Compressor
L in
R in
L out
R out
Limiter
2-Band EQ
2-Band EQ
Limiter
