110
Chapter 7. Adding Effects
INDIV 3
: Output to the INDIVIDUAL 3 jack in mono without
passing through Multi-effects.
INDIV 4
: Output to the INDIVIDUAL 4 jack in mono without
passing through Multi-effects.
The value on the right sets the volume of the Tone or Rhythm
Tone. When Multi-effects are being applied, this sets the
amount of the effect that is applied; when Multi-effects are
not applied, this sets the volume of the direct sound.
• When the Output Assign parameter (PATCH/
COMMON/PATCH COMMON)/(RHYTHM/
COMMON/RHYTHM COMMON) is set to anything
but TONE, the setting made here has no effect (p. 108).
• When the Type parameter (PATCH/COMMON/
STRUCT) has a setting of Type 2–10, the outputs of
Tones 1 and 2 will be combined with Tone 2, and the
outputs of Tones 3 and 4 will be combined with Tone 4.
For this reason, the setting of Tone 1 will follow the
setting of Tone 2, and the setting of Tone 3 will follow
the setting of Tone 4 (p. 73).
• When outputting in mono, the Pan setting is disabled.
• When the settings are such that signals are split and
output from the INDIVIDUAL 1 jack and INDIVIDUAL
2 jack, and no plug is inserted in the INDIVIDUAL 2
jack, the sounds from INDIVIDUAL 1 and INDIVIDUAL
2 are mixed together, then output from the
INDIVIDUAL 1 jack. This sound comprises the sounds
from the INDIVIDUAL 1 and 2 jacks.
If the Mix/Parallel parameter (SYSTEM/SETUP/
SYSTEM SETUP) is set to MIX, all sounds are output
from the OUTPUT A (MIX) jacks in stereo (p. 169).
• When setting the MFX, set the output destination with
the Output parameter (PATCH/EFFECTS/PATCH MFX
OUT)/(RHYTHM/EFFECTS/RHYTHM MFX OUT) for
the sound after it has passed through the Multi-effects
(p. 116).
• Chorus and Reverb are output in mono at all times.
• The output destination of the signal after passing
through the chorus is set with Output Assign parameter
or Select parameter (PATCH/EFFECTS/PATCH CHO
OUT)/(RHYTHM/EFFECTS/RHYTHM CHO OUT) (p.
158).
• The output destination of the signal after passing
through the reverb is set with Output Assign parameter
(PATCH/EFFECTS/PATCH REV OUT)/(RHYTHM/
EFFECTS/RHYTHM REV OUT) (p. 160).
For more on how to set each effect, refer to the pages
shown below.
• Multi-effects
→
• Chorus
→
• Reverb
→
Chorus (Chorus Send Level) ★
Sets the chorus depth for individual Tone/Rhythm Tone. If
you don’t want to add the Chorus effect, set it to 0.
Reverb (Reverb Send Level) ★
Sets the reverb depth for individual Tone/Rhythm Tone. If
you don’t want to add the Reverb effect, set it to 0.
5. Either rotate the VALUE dial or press [INC/+]/[DEC/-]
to set the value.
6. Press [EXIT] to return to the PATCH PLAY/RHYTHM
PLAY page.
An asterisk
*
will be displayed at the left of the Patch/
Rhythm Set group. This indicates that the Patch/Rhythm
Set settings have been modified.
If you select another Patch/Rhythm Set in the group
with an asterisk
*
, the modified Patch/Rhythm Set
settings will be lost. To keep these modified settings,
perform the save operation (p. 164).
