238
Parameter List
EFFECTS Group (p. 97)
Display Parameter Value
OUTPUT Output Assign Output assign MFX, OUTPUT A/B, INDIV 1–4 T
Output level 0–127 T
Chorus Chorus send level 0–127 T
Reverb Reverb send level 0–127 T
RHYTHM MFX TYPE Type Multi-effects type (*1)
RHYTHM MFX PRM (*1) Multi-effects parameters
RHYTHM MFX CTRL Source Multi-effects control source 1, 2, 3, 4 (*2)
Destination Multi-effects control destination 1, 2, 3, 4 (*3)
Sens Multi-effects control sensitivity 1, 2, 3, 4 -63– +63
RHYTHM MFX OUT Output Multi-effects output assign A, B
Dry Multi-effects dry send level 0–127
Chorus Multi-effects chorus send level 0–127
Reverb Multi-effects reverb send level 0–127
RHYTHM CHO TYPE Type Chorus type OFF, CHORUS, DELAY
RHYTHM CHO PRM (*4) Chorus parameters
RHYTHM CHO OUT Output Assign Chorus output assign A, B
Level Chorus level 0–127
Select Chorus output select MAIN, REV, MAIN+REV
RHYTHM REV TYPE Type Reverb type OFF, REVERB, SRV ROOM, SRV HALL, SRV PLATE
RHYTHM REV PRM (*5) Reverb parameters
RHYTHM REV OUT Output Assign Reverb output assign A, B
Level Reverb level 0–127
*1: Refer to “Multi-Effects Parameters” (p. 241).
*2: OFF, CC01–95 (except 32), PITCH BEND, AFTERTOUCH, SYS-CTRL1, SYS-CTRL2, SYS-CTRL3, SYS-CTRL4
*3: Refer to “Multi-Effects Types” (p. 117).
*4: Refer to “Chorus Parameters” (p. 248).
*5: Refer to “Reverb Parameters” (p. 249).
CONTROL Group (p. 97)
Display Parameter Value
CONTROL Bend Range Bend range 0–48 T
Envelope Mode Envelope mode NO-SUS, SUSTAIN T
Mute Group Mute group OFF, 1–31 T
Assign Type Assign type MULTI, SINGLE T
Rx MIDI Expression Receive expression switch OFF, ON T
Pan Receive pan mode CONTINUOUS, KEY-ON T
Hold-1 Receive hold 1 switch OFF, ON T
WAVE Group (p. 98)
Display Parameter Value
TONE NAME ---- Tone name ASCII Characters (max. 12) T
WMT WAVE Group Wave group INT, XP-A, XP-B, XP-C, XP-D T
Number Wave number (L, R) 0001–1083 W
Gain Wave gain -6, 0, 6, 12 dB W
Level Wave level 0–127 W
Sw Wave switch OFF, ON W
Tempo Sync Wave tempo sync OFF, ON W
WMT VEL RANG L.Fade Velocity fade width lower 0–127 W
Lower Velocity range lower 1–127 W
Upper Velocity range upper 1–127 W
U.Fade Velocity fade width upper 0–127 W
VELO CONTROL WMT Velocity Control WMT velocity control switch OFF, ON, RANDOM T
WMT PAN Pan Wave pan L64–0–63R W
Random Random pan switch OFF, ON W
Alternate Alternate pan switch OFF, ON W
WMT TUNE Coarse Coarse tune -48– +48 semitone W
Fine Fine tune -50– +50 cent W
WMT FXM Switch FXM switch OFF, ON W
Color FXM color 1–4 W
Depth FXM depth 1–17 W
