Roland XV-88 - Manual (Page 133)

133
Chapter 7. Adding Effects
Chapter 7
24: REVERB
The Reverb effect adds reverberation to the sound,
simulating an acoustic space.
fig.MFX-24
Type (Reverb Type)
Select the type of Reverb effect.
ROOM1 : dense reverb with short decay
ROOM2 : sparse reverb with short decay
STAGE1 : reverb with greater late reverberation
STAGE2 : reverb with strong early reflections
HALL1 : reverb with clear reverberance
HALL2 : reverb with rich reverberance
Pre Dly (Pre Delay Time)
Adjust the time delay from when the direct sound begins
until the reverb sound is heard.
Time (Reverb Time) #
Adjust the time length of reverberation.
HF Damp
Adjust the frequency above which the reverberant sound will
be cut. As the frequency is set lower, more of the high
frequencies will be cut, resulting in a softer and more muted
reverberance. If you do not want the high frequencies to be
cut, set this parameter to BYPASS.
LowGain (Low Gain)
Adjust the gain of the low frequency range.
Hi Gain (High Gain)
Adjust the gain of the high frequency range.
Balance (Effect Balance) #
Adjust the volume balance between the direct sound and the
reverb sound. With a setting of D100:0W only the direct
sound will be output, and with a setting of D0:100W only the
reverb sound will be output.
Level (Output Level)
Adjust the output level.
25: GATED REVERB
Gate Reverb is a special type of reverb in which the
reverberant sound is cut off before its natural length.
fig.MFX-25
Type (Gated Reverb Type)
Select the type of reverb.
NORMAL : conventional gate reverb
REVERSE : backwards reverb
SWEEP1 : the reverberant sound moves from right to left
SWEEP2 : the reverberant sound moves from left to right
Pre Dly (Pre Delay Time)
Adjust the time delay from when the direct sound begins
until the reverb sound is heard.
Gate Time
Adjust the time from when the reverb is heard until when it
disappears.
LowGain (Low Gain)
Adjust the gain of the low frequency range.
Hi Gain (High Gain)
Adjust the gain of the high frequency range.
Balance (Effect Balance) #
Adjust the volume balance between the direct sound and the
reverb sound. With a setting of D100:0W only the direct
sound will be output, and with a setting of D0:100W only the
reverb sound will be output.
Level (Output Level) #
Adjust the output level.
L in
R in
L out
R out
Reverb
2-Band
EQ
Balance W
Balance W
Balance D
Balance D
2-Band
EQ
L in
R in
L out
R out
Gated Reverb
2-Band
EQ
Balance W
Balance W
Balance D
Balance D
2-Band
EQ
