186
Chapter 10. Memory Settings (Utility Mode)
You can specify the data to be transmitted by selecting the
appropriate combination shown below.
For example, if you wish to transmit the USER group Patches
001-020, you would specify “PATCH USER:001-020.”
Type Block
ALL USER
TEMP
PERFORM USER 01–64
TEMP -PATCH *1
+PATCH *2
CTRL
PATCH USER 001–128
TEMP
RHYTHM USER 001–004
TEMP
SYSTEM USER
*1 Only the current Performance settings will be transmitted.
*2 The current Performance settings and the setting of a Patch
or Rhythm Set assigned to the Part will be transmitted.
Type (Data Type)
Specifies the type of data to be transmitted.
ALL : Performance, Patch, and Rhythm Set
PERFORM : Performance
PATCH : Patch
RHYTHM : Rhythm Set
SYSTEM : System
Block (Source Block)
Specifies the source of the data to be transmitted.
USER : Data from user memory will be transmitted.
TEMP : Data in Temporary area will be transmitted.
CTRL : The status of Performances, including Performance
Bank Selects and Program Changes, are not sent as Exclusive
messages, but rather as MIDI Channel messages.
For more on the messages that are transmitted, refer to
“MIDI Implementation” (p. 270).
Destination
This is the Transmission destination. It is set with MIDI.
Transmitting Data to the XV-88
You can transmit Performance, Patch or Rhythm Set settings
to the user memory and System settings to the System
memory. By loading sound data from a memory card or
Wave Expansion Boards to user memory, you can bring new
sounds into a Performance.
fig.10-27.e
• If the XV-88 internal memory already contains important
data that you have created, this operation will cause all
of this data to be lost. If you wish to keep the data, you
must save it on a memory card (p. 190) or on an external
MIDI device (p. 185).
• If Internal Write Protect is turned ON, the following
display will appear, and the Data Transfer operation will
not be executed.
fig.10-03
Change the displayed ON to OFF and press [ENTER] to
turn Internal Write Protect off. Press [ENTER] once
again.
Data type
Source block
Destination
