Chapter 1 User Interface
© National Instruments Corporation 1-43 NI Ultiboard User Manual
Spreadsheet View: Copper Areas Tab
Use the Copper Areas tab to work with information for copper areas.
Column Description
Layer The layer on which the copper area is found, as set in
the Copper Area Properties dialog box. Refer to the
Viewing and Editing Copper Properties section of
Chapter 5, Working with Traces and Copper , for more
information.
Locked Yes indicates that the copper area cannot be moved.
No indicates that the copper area can be moved.
Net The unique identifier for the net to which the copper
area is connected.
Trace
Clearance The minimum clearance permitted between the
copper area and traces, as set in the Copper Area
Properties dialog box. Refer to the
Viewing and
Editing Copper Properties section of Chapter 5,
Working with Traces and Copper , for more
information.
Thermal
Relief Style The style of thermal relief for the copper area, as set
in the Copper Area Properties dialog box. Refer to
the
Viewing and Editing Copper Properties section of
Chapter 5, Working with Traces and Copper , for more
information.
Spoke Width The size of the spokes a thermal relief, as set in the
Copper Area Properties dialog box. Refer to the
Viewing and Editing Copper Properties section of
Chapter 5, Working with Traces and Copper , for more
information.
