Chapter 1 User Interface
© National Instruments Corporation 1-11 NI Ultiboard User Manual
Place Text button. Places text on the design. Useful for
annotation purposes. Refer to the
Placing and Editing
Text section of Chapter 8, Preparing for
Manufacturing/Assembly , for more information.
Place a Standard Dimension button. Places a dimension
between any two selected points. Refer to the
Working
with Dimensions section of Chapter 4, Working with
Parts , for more information.
Place a Horizontal Dimension button. Places a
horizontally-oriented dimension between two selected
points. Refer to the
Working with Dimensions section of
Chapter 4, Working with Parts , for more information.
Place a Vertical Dimension button. Places a
vertically-oriented dimension between two selected
points. Refer to the
Working with Dimensions section of
Chapter 4, Working with Parts , for more information.
Place a Net Bridge button. Places a net bridge
connection. Refer to the
Net Bridges section of Chapter 5,
Working with Traces and Copper , for more information.
Place a Hole button. Places a hole on your PCB.
Place a Via button. Places a via on the design. Refer to
the
Working with Vias section of Chapter 5, Working with
Traces and Copper , for information.
Place Pins button. Places pins on the design when editing
or creating a part in In-place Edit mode or Footprint Edit
mode. Refer to the
Editing a Placed Part (In-Place Edit)
and Using the Database Manager to Create a Part
sections of Chapter 4, Working with Parts , for more
information.
Button Description
