Chapter 1 User Interface
© National Instruments Corporation 1-7 NI Ultiboard User Manual
Edit Toolbar
The Edit toolbar contains the functions used for editing specific elements,
including in-place editing and orientation. The Edit toolbar buttons are
explained in the table below.
Fill Style button. Sets the fill style, either transparent or solid.
Line Color button. Sets the color of the layer’s line.
Line Type button. Sets the lines style, for example, solid,
dashed.
Button Description
Toggle “In-Place” PCB Part Edit button. Activates
In-Place Edit for placed PCB parts. Refer to the
Editing
a Placed Part (In-Place Edit) section of Chapter 4,
Working with Parts , for more information.
Toggle “In-Place” Edit Text or Attribute button.
Allows you to edit the selected text.
Rotate Clockwise button. Rotates selected item
clockwise. Refer to the
Orienting Parts section of
Chapter 4, Working with Parts , for more information.
Rotate Counter Clockwise button. Rotates selected item
counter-clockwise. Refer to the
Orienting Parts section
of Chapter 4, Working with Parts , for more information.
Swap Layer button. Places a part on mirror layer. Refer
to the
Orienting Parts section of Chapter 4, Working with
Parts , for more information.
Button Description
