Chapter 1 User Interface
NI Ultiboard User Manual 1-10 ni.com
Place Ellipse button. Places an ellipse on the design.
Refer to the
Placing Shapes and Graphics section of
Chapter 4, Working with Parts , for more information.
Place Pie button. Places a pie-shape on the design. Refer
to the
Placing Shapes and Graphics section of Chapter 4,
Working with Parts , for more information.
Place Rounded Rectangle button. Places a rectangle
with rounded corners. Refer to the
Placing Shapes and
Graphics section of Chapter 4, Working with Parts , for
more information.
Place Rectangle button. Places a rectangle on the design.
Refer to the
Placing Shapes and Graphics section of
Chapter 4, Working with Parts , for more information.
Place Polygon button. Places a polygon on the design.
Refer to the
Placing Shapes and Graphics section of
Chapter 4, Working with Parts , for more information.
Place Copper Area button. Places a polygon copper area
on the design. Refer to the
Placing Copper Areas section
of Chapter 5, Working with Traces and Copper , for more
information.
Follow-me button. Places a follow me trace, a trace that
automatically draws a legal trace between two selected
points. Refer to the
Placing a Trace: Follow-me Method
section of Chapter 5, Working with Traces and Copper ,
for more information.
Place Multiple Traces as a Bus button. Use to connect
multiple traces between multi-pinned devices such as ICs.
Refer to the
Placing a Bus section of Chapter 5, Working
with Traces and Copper , for more information.
Place Group Array Box button. A group array box is
used to place parts in an array. Refer to the
Placing a
Group Array Box section of Chapter 4, Working with
Parts , for more information.
Button Description
