Chapter 1 User Interface
© National Instruments Corporation 1-3 NI Ultiboard User Manual
View Toolbar
The View toolbar contains buttons for modifying the way the screen is
displayed, and appears by default when you run Ultiboard. The View
toolbar buttons are explained in the table below.
Button Description
Redraw the Screen button. Redraws the currently active
design workspace. Refer to the
Refreshing the Design
section of Chapter 2, Beginning a Design , for more
information.
Toggle Full Screen button. Adjusts the size of the
workspace so it displays the entire design. Refer to the
Using the Full Screen section of of Chapter 2, Beginning
a Design , for more information.
Zoom In button. Zooms in on the design, providing a
closer view. Refer to the
Magnifying and Shrinking the
View section of Chapter 2, Beginning a Design , for more
information.
Zoom Out button. Zooms out on the design, providing a
broader view.
Zoom Window button. Magnifies a selected part of the
design. Refer to the
Magnifying and Shrinking the View
section of Chapter 2, Beginning a Design , for more
information.
Zoom Bounds button. Shows the entire design, including
objects that are outside of the board outline.
