178
Chapter 7 Installing Internal Options
7.3.3 How to Install a CPU
1
Turn the power off and remove the top cover.
"7.2 Removing and Attaching the Top Cover" (pg.174)
2
Touch a metal part of the server to discharge static electricity.
3
Remove the ventilation system cover.
Pull up and remove the ventilation system cover.
4
Remove the CPU dummy attached to CPU Socket 1.
Tilt the CPU dummy slightly to remove the four hooks and then pull it out.
Ventilation s
Slightly tilt to remove the hook
CPU dummy
