165
PRIMERGY RX300 S2 User’s Guide
5
Operatio
ns
after O
S
In
st
al
lation
3
Click [Add VLAN]. The following message may be displayed at the time. In such
a case, click [Yes].
4
Specify [ID] and [Name]. Then click [OK].
The [ID] should be identical with the switch setting.
The [Name] does not need to be identical with the switch setting.
5
Repeat Steps 3 through 5 to set respective VLANs.
6
Click [OK].
When setup of the VLAN is completed, the following virtual adapter will be created.
• "Intel(R) Advanced Network Services Virtual Adapter"
Upper protocols will be bound with the main virtual adapter. You cannot bind them with the LAN
card consisting a VLAN. The IP address should be specified in the main virtual adapter.
5.7.6 Local Address Setting
Specify a local address according to the following procedures.
1
Start up "Intel
®
PROSet". The procedure differs depending on the OS being
used.
For Windows Server 2003
1. Click [Start] → [Control Panel] → [Intel(R) PROSet].
For Windows 2000 Server
1. Click [Start] → [Settings] → [Control Panel].
The [Control Panel] window appears.
2. Start up "Intel(R) PROSet".
2
Select a LAN card to set the local address and click the [Advanced] tab.
3
Specify a local address in [Locally Managed Address].
You need to connect with the switch that supports IEEE
VLANs (802.1Q). Do you want to enable QOS Packet Tagging?
