ACCULINK 336x E1 NTU
3-2 December 1996 3360-A2-GB20-20
Overview
This chapter contains information for operating your
E1 NTU. It includes a description of the front panel and
sample procedures for configuring the E1 NTU.
Using the Front Panel
The E1 NTU front panel ( Figure 3-1 ) consists of an
LCD, a keypad, test jacks, and 12 LEDs.
NOTE
You can display a graphical
representation of the E1 NTU
front panel on an attached PC
(see Appendix G,
Front Panel
Emulation ).
F1 F2 F3
OK FAIL TEST SIG1 OOF ALRM
NETWORK RXD
SIG2 SIG ALRM PDV OOF BPV
LCD
Lp1
Lp2
In
Out
In
Out
HDSL
LINE
E1
LINE
E1
MON
DTR TXD CTS RTS
496-14728-01
KEYPAD
TEST JACKS LEDs
Figure 3-1. E1 NTU Front Panel
