SNMP MIB Objects
E-17 3360-A2-GB20-20 December 1996
Table E-1
(2 of 4)
SNMP MIB to Front Panel Command Cross-Reference
Front Panel Command SNMP MIB Object
Stat–>Tstat:
LLB Test Active
PLB Test Active
RLB Test Active
DLB Test Active
DCLB on Port
n
DTLB on Port n
32767 Test Active
1–8 Test Active
QRSS on Port
n
511 on Port n
Mon QRSS, Port n
Mon511, Port n
Mon 32767, Net E1
Read:
dsx1LineLoop from dsx1LoopbackConfig for Net E1
dsx1PayloadLoop from dsx1LoopbackConfig for Net E1
dsx1PayloadLoop from dsx1LoopbackConfig for DTE E1
dsx1LineLoop from dsx1LoopbackConfig for DTE E1
testFullDuplexLoopback from IfExtnsTestType for Port n
testLoopDTLB from IfExtnsTestType for Port n
testSend32767 from ifExtnsTestType for Net E1
testSend1in8 from ifExtnsTestType for Net E1
testSendQRSS from IfExtnsTestType for Port n
testSend511 from IfExtnsTestType for Port n
testMonQRSS from ifExtnsTestType for Port n
testMon511 from ifExtnsTestType for Port n
testMon32767 from ifExtnsTestType for Net E1
Stat–>LED–>Prt n:
DTR
CTS
RTS
Read:
rs232InSigState from rs232InSigName == dtr
rs232outSigState from rs232OutSigName == cts
rs232InSigState from rs232InSigName == rts
Stat–>ID:
Ser
Mod
SRev
HRevCCA1
HRevCCA2
HRevCCA3
Read sysDescr object from the System Group
Test–>Rlpbk–>DCLBUP–>Prt n Set IfExtnsTestType for port n to testSendV54Up
Test–>Rlpbk–>DCLBDN–>Prt n Set IfExtnsTestType for port n to testSendV54Down
Test–>Lpbk–>LLB
Test–>Lpbk–>Abort–>LLB Set dsx1LoopbackConfig for NET E1 to dsx1LineLoop
Set dsx1LoopbackConfig for NET E1 to dsx1NoLoop
Test–>Lpbk–>PLB
Test–>Lpbk–>Abort–>PLB Set dsx1LoopbackConfig for NET E1 to dsx1PayloadLoop
Set dsx1LoopbackConfig for NET E1 to dsx1NoLoop
Test–>Lpbk–>DLB
Test–>Lpbk–>Abort–>DLB Set dsx1LoopbackConfig for DTE E1 to dsx1LineLoop
Set dsx1LoopbackConfig for DTE E1 to dsx1NoLoop
Test–>Lpbk–>RLB
Test–>Lpbk–>Abort–>RLB Set dsx1LoopbackConfig for DTE E1 to dsx1PayloadLoop
Set dsx1LoopbackConfig for DTE E1 to dsx1NoLoop
