ACCULINK 336x E1 NTU
E-18 December 1996 3360-A2-GB20-20
Table E-1
(3 of 4)
SNMP MIB to Front Panel Command Cross-Reference
Front Panel Command SNMP MIB Object
Test–>Lpbk–>DCLB–>Prt n
Test–>Lpbk–>Abort–>DCLB–>Prt n
Set IfExtnsTestType for port n to testFullDuplexLoopBack
Set dsx1LoopbackConfig for port n to noTest
Test–>Lpbk–>DTLB–>Prt n
Test–>Lpbk–>Abort–>DTLB–>Prt n
Set IfExtnsTestType for port n to testLoopDTLB
Set dsx1LoopbackConfig for port n to noTest
Test–>Ptrns–>Send–>QRSS–>Prt n
Test–>Ptrns–>Abort–>Send–>Prt n
Set IfExtnsTestType for port n to testSendQRS
Set IfExtnsTestType for port n to noTest
Test–>Ptrns–>Send–>32767
Test–>Ptrns–>Abort–>Send–>NET Set ifExtnsTestType for NET E1 to testSend32767
Set ifExtnsTestType for NET E1 to noTest
Test–>Ptrns–>Send–>1in8
Test–>Ptrns–>Abort–>Send–>NET Set ifExtnsTestType for NET E1 to testSend1in8
Set dsx1SendCode for NET E1 to dsx1SendNoCode
Test–>Ptrns–>Send–>511–>Prt n
Test–>Ptrns–>Abort–>Send–>Prt n
Set IfExtnsTestType for port n to testSend511
Set IfExtnsTestType for port n to noTest
Test–>Ptrns–>Mon–>QRSS–>Prt n
Test–>Ptrns–>Abort–>Mon–>Prt n
Set ifExtnsTestType for port n to testMonQRSS
Set ifExtnsTestType for port n to noTest
Test–>Ptrns–>Mon–>511–>Prt n
Test–>Ptrns–>Abort–>Mon–>Prt n
Set ifExtnsTestType for port n to testMon511
Set ifExtnsTestType for port n to noTest
Test–>Ptrns–>Mon–>32767–>NET
Test–>Ptrns–>Abort–>Send–>NET Set ifExtnsTestType for NET E1 to testMon32767
Set dsx1SendCode for NET E1 to dsx1SendNoCode
Cnfig–>Load Cnfig–>Save Set devConfigAreaCopy to desired choice (Active to Customer1, etc.)
Cnfig–>Activ–>Edit–>DTE–>DTE–>Frame Set/Display dsx1LineType for DTE E1 to dsx1E1 or dsxE1-CRC
Cnfig–>Activ–>Edit–>DTE–>DTE–>Coding Set/Display dsx1LineCoding for DTE E1 to dsx1HDB3 or dsx1AMI
Cnfig–>Activ–>Edit–>Port–>Prtn->Port Type Display rs232PortType for port n to rs422, v35, or X.21
Cnfig–>Activ–>Edit–>Port–>Prt n–>TxClock Set/Display rs232SyncPortClockSource for port n to internal or
external
Cnfig–>Activ–>Edit–>NET–>NET Frame Set/Display dsx1LineType for NET E1 to dsx1E1 or dsxE1-CRC
Cnfig–>Activ–>Edit–>NET–>Mgmt Link Set/Display dsx1Fdl for NET E1 to dsx1other or dsx1FDL-none
