Model 3086 G.SHDSL IAD overview
Ethernet port (outlined in green)
Shielded RJ-45 10Base-T/100Base-TX Ethernet port using pins 1,2,3, & 6. See MDI-X switch for hub or transceiver
configuration.The following table defines conditions that occur when the MDI-X switch is in the out position.
MDI-X
The MDI-X push switch operates as follows:
•
When in the default “out” position, the Ethernet circuitry takes on a straight-through MDI configuration
and functions as a transceiver. It will connect directly to a hub.
•
When in the “in” position, the Ethernet circuitry is configured in cross-over MDI-X mode so that a
straight-through cable can connect the Model 3086 DSL modem’s Ethernet port directly to a PC’s NIC
card.
Line port (outlined in yellow)
The RJ-11/4 DSL line port uses pins 2 and 3 of the RJ-11 port.
Pin No. Signal Direction Signal Name
1
Output
TX+
2
Output
TX-
3
Input
RX+
4
—
—
5
—
—
6
Input
RX-
7
—
—
8
—
—
Pin No.
Signal Name
1
—
2
In/Out-A
3
In/Out-B
4
—
