Remote Control (4 & 8 Channel)
Remote Control (4 & 8 Channel)
The remote control is the secondary input
device for navigating the system’s interface.
To use the remote control:
1
Number Keys (1 -9)
: Selects the desired
channel in full screen mode
•
0
: Press
0
three times to switch between VGA
output and BNC Video Out output.
•
: Changes view of system channel (i.e.
Channels 1-4, 5-8, split-screen etc.)
•
MENU
: Opens the Main Menu. Within menus,
the MENU button is used to exit the menu.
2
Navigation Cursors
: Use the navigation
cursors to navigate the menu.
•
: Confirms the selection in the menu.
• Press
to access System Information
during live view.
3
SUB MENU
: Opens the system sub menu.
4
MUTE
: Mutes audio channel during live view
and playback.
5
Playback Controls
:
•
: During playback, press repeatedly to
increase playback speed
•
: During playback, press repeatedly to
increase reverse playback speed
•
:
• In live view, press to open the Record
Search Menu
• During playback, press to play video.
•
:
• In live view, press to start sequence
view. During playback, press to pause
video
•
: Record: Press to resume recording
•
: Press to stop recording.
1
2
3
4
5
*Audio capable cameras (not included) are required for audio
recording and listen-in audio functionality.
TIP: When using the remote
control to enter password and
camera titles, select the field
using the navigation buttons,
press
, and then press the
number buttons.
.
.
