Appendix E: Internet Setup Wizard (PC only)
Step 2: Enter your router settings
1
Under the Router drop-down list, select the model of your router.
OR
• Click the Search button (
) to enter the name of your router model.
NOTE: Click the Auto Detect button (
)if you have a Linksys or Netgear router (works with
most Linksys or Netgear models).
2
Under Router IP, click the Detect Router IP button (
).
• The router’s IP populates in the blank field. Click OK to exit the prompt.
3
Under Username and Password, enter
the router’s
username and password.
• Optional: Under HTTP Type (default http://) and HTTP Port (default, 80), you may have to
change the values depending on your router model. Consult your router manual for details.
4
Under IP, enter the IP address of your Lorex device.
• To find your system IP, exit to the main viewing mode, and then press the INFO button on your
remote, or press the RETURN button on the front panel of the system.
5
Under Port, enter the Web Port (80). Under 2nd Port, enter the Media port (9000). Under 3rd
port, enter the Mobile Port (1025).
6
Click Next to continue.
Search and Auto detect
button
Router drop-down list
Router IP
Router user name &
password
80
9000
Enter port
80
under
Ports
Enter port
9000
under 2nd Port
Enter port
1025
under 3rd Port
1025
Enter your Lorex
device’s IP
Enter port
number
