Appendix O: Remote Viewing (Mac)
Appendix O: Remote Viewing (Mac)
Prerequisite:
• Follow the steps on page 54 to page 59 to set up remote viewing on the DVR.
Remote Viewing Interface
1
Navigation Tabs: Allows you to access the following tabs:
• Live: Live view of video
• Playback: Revisit archived video footage
• Remote Config: Configure DVR settings remotely.
• Local Config: Configure where your saved files and images are saved.
• Logout: Exits remote viewing
2
Active Channel List: Displays channels that are currently live. Purple play buttons indicate
viewing is active.
3
Main Screen
: Main display screen for live viewing and playback.
4
Toolbar: The system tool bar allows you to change viewing modes, start playback, take image
snapshots, and control audio volume.
5
PTZ Controls: PTZ (Pan, Tilt, Zoom) control for connected PTZ cameras (not included).
1
2
3
4
5
