12

Mouse Control

Mouse Control

The system is designed for mouse navigation. To use the mouse, connect the mouse to the
rear USB panel on the DVR.

1

Use the mouse buttons to perform the following:
Left-Button: Click to select a menu option;

during live viewing in split-screen, double-click
on a channel to view the selected channel in
full-screen.; double-click the channel again to
return to split-screen view

2

Right-Button:

• Click to open the Sub-Menu (see “Using the

Sub-Menu” on page 18.).

• In menus, use the right-button to exit menus.

3

Scroll-Wheel: No function.

*8-channel model shown

4/8 Channel Model

Plug the mouse into the top USB port.

Plug the mouse into the top USB port

16 Channel Model

1

2

3
