AI296 Version 9.8x User’s Guide
Link Configuration: BX.25 Configuration
6-5
BX.25 Configuration
AI296 is BX.25 compatible and implements passive links. Passive links are not a part
of the BX.25 protocol. Once a passive link is active, it uses the BX.25 protocol.
Notes: BX.25 is supported on only one link per AI296.
Some BX.25 parameters may vary based on the AI296 installation.
The following configuration components are available:
z BX.25 Configuration Values Usage
z BX.25 Modulo
z BX.25 Support
z BX.25 Timer Settings
BX.25 Configuration Values Usage
Description
This menu item enables or disables the use of the values configured in the BX.25
menu.
Menu Item Type
Toggle
Link Type Availability
X.25
Configuration in the AI198 Menu System
1. Access Menu 4.2.11.12.11.
2. For 02*Use these configuration values , enter 2 to select Enabled or Disabled . The
default is Enabled .
This example displays 02*Use these configuration values set to Enabled .
>2
Menu 4.2.11.12.11
01*BX25 Support (Enabled, Disabled)------------------------------------ Enabled
02*Use these configuration values (Enabled, Disabled)------------------ Enabled
