AI296 Version 9.8x User’s Guide
Link Configuration: General Link Properties Configuration
6-35
This example displays Port data bits set to Seven .
Port Parity
Description
This menu item defines parity, which is a process for detecting whether or not bits of
data have been altered during data transmission.
Menu Item Type
Toggle
Link Type Availability
Async and AsyncPPP
Configuration in the AI198 Menu System
1. Access Menu 4.2.11.12.
2. For 08*Port Parity , enter 8 to select None , Odd , or Even . The default is None .
This example displays 08*Port Parity set to Odd .
Configuration in the AI296 Local Menu System
1. Access the Async Link Menu or AsyncPPP Link Menu.
2. For Port parity , select None , Even , or Odd . The default is None .
Async Link Menu
Link to configure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Link state . . . . . . . . . . . . . . . . . . . . . . . . . . Up [Down]
Link Type . . [Async] X.25 HDLC-Bridge SyncPPP AsyncPPP MLT
Interface Type . . . . . . . . . . . . . . . . . [RS-232] RS-530 V.35
Port speed (in bits per second):
300 1200 2400 4800 [9600] 19.2K 38.4K 57.6K 115.2K
Autobaud
Port data bits . . . . . . . . . . . . . . . . . . . . . . [Seven] Eight
>8
Menu 4.2.11.12
01 Link Number (1-16)--------------------------------------------------------01
02*Link Type (Async, X25, HDLC, SyncPPP, AsyncPPP, MLT)---------------- Async
03 Link Description------------------------------ Async link 1
04*Link state (Enabled, Disabled)-------------------------------------- Enabled
05+Port speed------------------------------------------------------------- 9600
06*Port Data Bits (7, 8)------------------------------------------------------8
07*Port Stop Bits (1, 2)------------------------------------------------------1
08*Port Parity (None, Odd, Even)------------------------------------------- Odd
