AI296 Version 9.8x User’s Guide
Link Configuration: General Link Properties Configuration
6-30
This example displays 05*Link mode set to Passive .
Configuration in the AI296 Local Menu System
1. Access the X.25 Link Menu.
2. From the X.25 Link Menu, select Quick X.25 Menu . The Quick X.25 Menu appears.
3. For X25 Passive Link Mode , select Normal , Passive , or Extended . The default is normal.
This example displays X25 Passive Link Mode set to Passive .
Link Number
Description
This menu item defines the number of the link being configured.
Menu Item Type
Data
Link Type Availability
Async, AsyncPPP, HDLC-Bridge, MLT, SyncPPP, and X.25
Configuration in the AI198 Menu System
1. Access Menu 4.2.11.12.
2. For 01 Link number , enter 1, and the link number. The default is 1 .
>5
Menu 4.2.11.12
01 Link number (1-16)--------------------------------------------------------01
02*Link Type (Async, X25, HDLC, SyncPPP, AsyncPPP, MLT)---------------- X.25
03 Link Description------------------------------ Async link 1
04*Link state (Enabled, Disabled)-------------------------------------- Enabled
05*Link mode (Normal, Passive, Extended)------------------------------- Passive
Quick X.25 Menu
Link being configured . . . . . . . . . . . . . . . . . . . . . . . . . 03
Interface Mode . . . . . . . . . . . . . . . . . . . . . . . DTE [DCE]
Port speed (0=external clocking) . . . . . . . . . . . . . . . . . . . . 4800
X25 Passive Link Mode . . . . . . . . . . . Normal [Passive] Extended
