AI296 Version 9.8x User’s Guide
AI296 Commands: diag-line
9-47
Tip: Press ENTER to execute a command and press ESC to end the diagnostic
session.
CAUTION: If you are connected to AI296 through a serial port, do not monitor the
port with command
diag-line
. Use command
hide
to hide and not
monitor the port. Failure to comply with this statement can cause AI296
to become unresponsive.
Command Type
shell
Formats
diag-line
interpret [ a | x ]
Toggles the display of decoded packet data on the line
monitor on or off and optionally selects the format of the data
in the data portion of the packet (
a
or
x
).
z
a
displays the data in the data portion of the packet in
ASCII/hexadecimal format. Unprintable data
(hexadecimal values 0x00 to 0x20 and 0x7F to 0xFF)
appears as two digit hexadecimal numbers separated by
a space. Printable data appears as printable characters.
This option only applies to data.
z
x
displays all the data in the data portion of the packet in
hexadecimal format. All data appears as two-digit
hexadecimal numbers separated by a space. This option
only applies to data.
Prints the range of revealed LCNs for all lines.
CTRL+
s
Pauses the line monitor.
go
or CTRL+
q
Reactivates the line monitor after displaying the line monitor
options.
ESC or
q
Quits monitoring traffic, exits from the line monitor, and
returns to the prompt.
?
Displays a list of the options available for line monitoring
diagnostics.
Table 9-2 Line Monitor Mode Options (Continued)
Option
Function
