AI296 Version 9.8x User’s Guide
Link Configuration: General Link Properties Configuration
6-41
This example displays 10 Xon Repeat interval set to 30 .
Configuration in the AI296 Local Menu System
1. Access the Async Link Menu or AsyncPPP Link Menu.
2. For XON Repeat Interval , enter a interval value. The default is 0 .
This example displays XON Repeat Interval set to 30 .
>10,30
Menu 4.2.11.12
01 Link Number (1-16)--------------------------------------------------------01
02*Link Type (Async, X25, HDLC, SyncPPP, AsyncPPP, MLT)---------------- Async
03 Link Description------------------------------ Async link 1
04*Link state (Enabled, Disabled)-------------------------------------- Enabled
05+Port speed------------------------------------------------------------- 9600
06*Port Data Bits (7, 8)------------------------------------------------------8
07*Port Stop Bits (1, 2)------------------------------------------------------1
08*Port Parity (None, Odd, Even)-------------------------------------------None
09*Flow Control (None, XonXoff)----------------------------------------- None
10 Xon Repeat interval (0 - 120s with 0 = no repeat)------------------------030
Async Link Menu
Link to configure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Link state . . . . . . . . . . . . . . . . . . . . . . . . . . Up [Down]
Link Type . . [Async] X.25 HDLC-Bridge SyncPPP AsyncPPP MLT
Interface Type . . . . . . . . . . . . . . . . . [RS-232] RS-530 V.35
Port speed (in bits per second):
300 1200 2400 [4800] 9600 19.2K 38.4K 57.6K 115.2K
Autobaud
Port data bits . . . . . . . . . . . . . . . . . . . . . . Seven [Eight]
Port stop bits . . . . . . . . . . . . . . . . . . . . . . . . One [Two]
Port parity . . . . . . . . . . . . . . . . . . . . . None Even [Odd]
SW Flow Control . . . . . . . . . . . . . . . . . . . . . [None] XonXoff
XON Repeat Interval (0 - 120s with 0 = no repeat) . . . . . . . . . . . . 30
