Kentrox AI296 User Manual
Page 183
AI296 Version 9.8x User’s Guide
Link Configuration: Virtual Circuit Configuration
6-89
This example displays:
z
01*PVC Type
set to
Connect
z
02 LCN Low
set to
5
z
03 LCN High
set to
15
z
04 INACTIVITY Timer Interval
set to
240
.
Configuration in the AI296 Local Menu System
1. Access the X.25 Link Menu.
2. Select
Quick X.25 Menu
. The Quick X.25 Menu appears.
3. For
Number of PVCs
, enter the number of PVCs to be configured. The default is
0
.
4. For
SVC Low
, enter a minimum SVC value that is higher than the number of PVCs.
Valid values are from
0
to
4095
. The default is
1
.
5. For
SVC High
, enter a maximum SVC value that is higher than the minimum SVC
value. Valid values are from
0
to
4095
. The default is
1
.
6. Save your work.
7. From the Quick X.25 Menu, select
PVC Menu
. The PVC Summary Menu appears.
8. For
Edit PVC
, enter the number of the PVC to be edited. This value must be in the
range of configured PVCs. The PVC Edit Menu appears.
9. For
Low PVC
, enter the minimum PVC value.
10. For
High PVC
, enter the maximum PVC value.
11. For
PVC Type
, select
Passive
,
Active
, or
ConnectOnActivity
. The default is
Passive
.
12. For
Timer Value
, select the timer interval value.
Passive
Reset Timer
0 s
0 s
>4,240
Menu 4.2.11.12.9.2.1
01*PVC Type (Passive, Active, Connect on activity)----------------------Connect
02 LCN Low (* for all LCNs for the link)-----------------------------------0005
03 LCN High----------------------------------------------------------------0015
04 INACTIVITY Timer Interval (seconds)------------------------------------00240
Table 6-1 PVC and Timer Type (Continued)
PVC Type
Timer Type
Range
Default
