AI296 Version 9.8x User’s Guide
Link Configuration: BX.25 Configuration
6-7
Configuration in the AI296 Local Menu System
1. Access the X.25 Link Menu.
2. Select BX.25 Menu . The BX.25 Menu appears.
3. For BX.25 Modulo , enter the desired value. The default is 256 .
This example displays BX.25 Modulo set to 150 .
BX.25 Support
Description
This menu item enables or disables BX.25 module support on a link. BX.25 support
can only be enabled on one link at a time. When enabling BX.25 support, first disable
support on all other links.
Menu Item Type
Toggle
Link Type Availability
X.25
Configuration in the AI198 Menu System
1. Access Menu 4.2.11.12.11.
2. For 01*BX25 Support , enter 1 to select Enabled or Disabled . The default is Disabled .
This example displays 01*BX25 Support set to Enabled .
BX.25 Menu
Link being configured . . . . . . . . . . . . . . . . . . . . . . . . . 03
BX.25 Support . . . . . . . . . . . . . . . . . . . . Enabled [Disabled]
Use BX.25 Configuration Values. . . . . . . . . . . . [Enabled] Disabled
Sending Unit Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
BX.25 Modulo. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .150
>1
Menu 4.2.11.12.11
01*BX25 Support (Enabled, Disabled)------------------------------------ Enabled
