AI296 Version 9.8x User’s Guide
IP Over X.25 Subnet Configuration: Local Settings
5-3
Local Settings
IXE can be configured using either one local and one remote AI296 or one local AI296
and a router that supports IP over X.25. The following configuration components are
available:
z Local IP Address for this Subnet
z Local IP Subnet Mask
z Local X.25 Link Number
Local IP Address for this Subnet
Description
This menu item configures the local IXE doorway address for the subnet.
Note: This address is not the same as the local AI296 IP address.
Menu Item Type
Data
Configuration in the AI198 Menu System
1. Access Menu 4.2.11.13. This menu displays a list of all the configured IP over
X.25 subnets.
2. From Menu 4.2.11.13, enter a value ( 02 through 11 ) associated with the IP over
X.25 subnet to be configured. Menu 4.2.11.13.1 appears.
3. For 01 Local IP address for this subnet , enter the subnet IP address value. The
default is 0.0.0.0 .
This example displays 01 Local IP address for this subnet set to 24.35.132.67 .
Configuration in the AI296 Local Menu System
1. Access the IP Over X.25 Subnet Menu.
2. From the IP Over X.25 Subnet Menu, select Add . The IP Over X.25 Subnet Edit
Menu appears.
3. For Local IP Address for this Subnet , enter the subnet IP address value.
>1,24.35.132.67
Menu 4.2.11.13.1
01 Local IP address for this subnet-----------------------------024.035.132.067
