AI296 Version 9.8x User’s Guide
AI296 Commands: diag-info
9-38
Examples
This example displays the WAN Diag Info screen, which is accessed by typing
W
.
This example displays diagnostic information for STREAMS allocation and memory,
which are accessed by typing
M
.
W A N D I A G I N F O
LINK STATE TX_PEND RX_WANT NO_BUF BYTE_IN BYTE_OUT
1 30 0 1 0 0 759050
2 0 0 1 0 0 0
3 0 0 1 0 0 0
4 0 0 1 0 0 0
5 0 0 1 0 0 0
6 0 0 1 0 0 0
7 0 0 1 0 0 0
8 0 0 1 0 0 0
9 0 0 1 0 0 0
10 0 0 1 0 0 0
11 0 0 1 0 0 0
12 0 0 1 0 0 0
13 0 0 1 0 0 0
14 0 0 1 0 0 0
15 0 0 1 0 0 0
16 0 0 1 0 0 0
Enter W-an, M-emory, A-sync, E-thernet, T-cp or Q-uit:
Column
Description
LINK
Displays the link number.
STATE
Displays the state of the WAN driver. Two states are available:
z
0 means the X.25 frame level is not established.
z
30 means the X.25 frame level is established.
TX_PEND
Displays the state of the transaction if one is pending for transmission.
RX_WANT
Displays the state of the buffer if another buffer is needed.
NO_BUF
Displays the number of times the receiver cannot be started because no
buffers were available.
BYTE_IN
Displays the count of the number of bytes coming in.
BYTE_OUT
Displays the count of the number of bytes going out.
