AI296 Version 9.8x User’s Guide
Link Configuration: X.25 Parameters Configuration
6-78
Configuration in the AI296 Local Menu System
1. Access the X.25 Link Menu.
2. Select X.25 Parameters Menu . The X.25 Parameters Menu appears.
3. For Protocol Version , select 1980 , 1984 , or 1988 . The default is 1984 .
This example displays Protocol Version set to 1988 .
X.25 Counter Settings
Description
The X.25 counter settings are configured using four menu items:
z R20 restart counter —Defines the maximum number of times a reset can be sent
without receiving reset confirmation.
z R22 reset transmission counter —Defines the maximum number of times a reset
can be sent without receiving clear confirmation.
z R23 clear transmission counter —Defines the maximum number of times a clear
request can be sent without clearing confirmation.
z R28 registration transmission counter —Defines the maximum number of times a
registration request can be sent without receiving registration confirmation.
Menu Item Type
Data
X.25 Parameters Menu
Link being configured . . . . . . . . . . . . . . . . . . . . . . . . . 03
X25 Facilities Negotiation . . . . . . . . . . . . . Enabled [Disabled]
Max Packet Size . . . . . . . . . . . . . . . . . . . . [128] 256 512
Packet Window Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
X121 Local Address . . . . . . . . . . . . . . . . . . . . . ................
T20 Restart Timer . . . . . . . . . . . . . . . . . . . . . . . . . . .1750000
T21 Call Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . .1000000
T22 Reset Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . .. 20000
T23 Clear Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . 180000
T24 Window Timer . . . . . . . . . . . . . . . . . . . . . . . . . . .2356000
T25 Data Retransmission Timer . . . . . . . . . . . . . . . . . . . . .1650000
T26 Interrupt Timer . . . . . . . . . . . . . . . . . . . . . . . . . .2300000
T28 Registration Timer . . . . . . . . . . . . . . . . . . . . . . . .. 90000
R20 Restart Counter . . . . . . . . . . . . . . . . . . . . . . . . . . . .150
R22 Reset Transmission Counter . . . . . . . . . . . . . . . . . . . . . . 25
R23 Clear Transmission Counter . . . . . . . . . . . . . . . . . . . . . . 34
R28 Registration Transmission Counter . . . . . . . . . . . . . . . . . . . 52
Protocol Version . . . . . . . . . . . . . . . . . 1980 1984 [1988]
