AI296 Version 9.8x User’s Guide

Alias and Call Routing Configuration: Alias Configuration Examples

8-54

This example displays AI296 configured to listen for all SVC calls on links 1 and 3 and
route those calls to links 2 and 4 (as displayed in

Figure 8-6 on page 8-53

Alias Edit Menu

Alias Name . . . . . ............................................. X25.1.SVC

Destination . . . . .......................................................
Caller's Address . . .......................................................
Called Address . . . ............................................... X25LL.2
Call Data . . . . . .......................................................

Caller's Protocol . .......................................................
Called Protocol . . .......................................................

Application String . .......................................................
Alternate Route . . .......................................................
Description . . . . .......................................................

Display Alias in Destination Menu . . . . . . . . . . . . . . [Yes] No
Alias Location . . . . . . . . . . . . . . . . . . . Beginning [End]

+ Alias Test Menu

Help Send Close Return to Main Menu

Alias Edit Menu

Alias Name . . . . . ............................................. X25.3.SVC

Destination . . . . .......................................................
Caller's Address . . .......................................................
Called Address . . . ............................................... X25LL.4
Call Data . . . . . .......................................................

Caller's Protocol . .......................................................
Called Protocol . . .......................................................

Display Alias in Destination Menu . . . . . . . . . . . . . . [Yes] No
Alias Location . . . . . . . . . . . . . . . . . . . Beginning [End]

+ Alias Test Menu

Help Send Close Return to Main Menu
