AI296 Version 9.8x User’s Guide
Link Configuration: Virtual Circuit Configuration
6-92
This example displays:
z
03 Incoming only SVC low
set to
8
z
04 Incoming only SVC high
set to
64
z
05 Two-way SVC low
set to
75
z
06 Two-way SVC high
set to
85
z
07 Outgoing only SVC low
set to
100
z
08 Outgoing only SVC high
set to
150
.
Configuration in the AI296 Local Menu System
1. Access the X.25 Link Menu.
2. Select
Quick X.25 Menu
. The Quick X.25 Menu appears.
3. For
SVC Low
, enter a minimum SVC value that is higher than the number of PVCs.
The default is
1
.
4. For
SVC High
, enter a maximum SVC value that is higher than the minimum SVC
value. The default is
1
.
This example displays
SVC Low
set to
10
and
SVC High
set to
15
.
>8,150
Menu 4.2.11.12.9
01 Number of PVCs (0 - 1024)-----------------------------------------------0005
02+PVC configuration
03 Incoming only SVC low (0 - 4095)----------------------------------------0008
04 Incoming only SVC high (0 - 4095)---------------------------------------0064
05 Two-way SVC low (0 - 4095)----------------------------------------------0075
06 Two-way SVC high (0 - 4095)---------------------------------------------0085
07 Outgoing only SVC low (0 - 4095)----------------------------------------0100
08 Outgoing only SVC high (0 - 4095)---------------------------------------0150
Quick X.25 Menu
Link being configured . . . . . . . . . . . . . . . . . . . . . . . . . 03
Interface Mode . . . . . . . . . . . . . . . . . . . . . . . DTE [DCE]
Port speed (0=external clocking) . . . . . . . . . . . . . . . . . . . . 4800
X25 Passive Link Mode . . . . . . . . . . . [Normal] Passive Extended
Passive Link with Clocking . . . . . . . . . . . . . Enabled [Disabled]
Frame Level Disconnect . . . . . . . . . . [Active] Passive Other
Frame Window Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Max Packet Size . . . . . . . . . . . . . . . . . . . . [128] 256 512
Packet Window Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
X121 Local Address . . . . . . . . . . . . . . . . . . . . . ................
Number of PVCs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
+ PVC Menu
SVC Low . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
SVC High . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
