AI296 Version 9.8x User’s Guide
Link Configuration: Virtual Circuit Configuration
6-90
The timer type, range, and default settings depend on the PVC type. Refer to
for PVC types, timer types, ranges, and defaults.
This example displays:
z
Low PVC
set to
30
z
High PVC
set to
50
z
PVC Type
set to
Active
z
Timer Value
set to
230
.
SVC Configuration Settings
Description
SVCs are network connections that are established when transmission is required
and are disconnected when the session is complete. The SVC settings are configured
using the following menu items:
z
Incoming only SVC low
—Defines the minimum LCN used for incoming only SVCs.
z
Incoming only SVC high
—Defines the maximum LCN used for incoming only SVCs.
z
Two-way SVC low
—Defines the minimum LCN used for an SVC.
z
Two-way SVC high
—Defines the maximum LCN used for an SVC.
z
Outgoing only SVC low
—Defines the minimum LCN used for outgoing only SVCs.
AI296 can place calls on outgoing only SVCs greater than the maximum PVC
and/or two-way SVC.
z
Outgoing only SVC high
—Defines the maximum LCN used for outgoing only SVCs.
AI296 can place calls on outgoing only SVCs.
Table 6-2 PVC and Timer Type
PVC Type
Timer Type
Range
Default
Active
Call Timer
30 to 600 s
30 s
Connect on Activity
Inactivity Timer
1 to 600 s
1 s
Passive
Reset Timer
0 s
0 s
PVC Edit Menu
Link being configured . . . . . . . . . . . . . . . . . . . . . . . . . . 03
Low PVC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. 30
High PVC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. 50
PVC Type . . . . . . . . . . . . . Passive [Active] ConnectOnActivity
Timer Value . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 230
