AI296 Version 9.8x User’s Guide
Link Configuration: LAPB Parameters Configuration
6-50
This example displays:
z 05 T1 ack timer set to 19000
z 06 T2 ack delay timer set to 20000
z 07 T4 idle timer set to 50000 .
Configuration in the AI296 Local Menu System
1. Access the MLT or X.25 Link Menu.
2. Select LAPB Menu or X.25 LAPB Menu . The MLT LAPB Menu or X.25 LAPB Menu
appears.
3. For T1 Ack Timer , enter the timer value. The default is 3000 .
4. For T2 Ack Delay Timer , enter the timer value. The default is 4000 .
5. For T4 Idle Timer , enter the timer value. The default is 25000 .
This example displays:
z T1 Ack Timer set to 19000
z T2 Ack Delay Timer set to 20000
z T4 Idle Timer set to 50000 .
N2 Retry Counter
Description
This menu item defines the maximum number of accepted retransmissions for
unacknowledged frames.
>7,50000
Menu 4.2.11.12.8
01*Interface mode (DTE or DCE)----------------------------------------------DCE
02*Frame level disconnect (Active, Passive, Other)---------------------- Active
03 Frame Window size (1 - 7)--------------------------------------------------7
04 N2 retry count (0 - 255)-------------------------------------------------150
05 T1 ack timer (100 - 25500 ms)------------------------------------------19000
06 T2 ack delay timer (100 - 25500 ms)------------------------------------20000
07 T4 idle timer (0 - 200000 ms)-----------------------------------------050000
MLT LAPB Menu
Link being configured . . . . . . . . . . . . . . . . . . . . . . . . . 03
Frame Level Disconnect . . . . . . . . . . . [Active] Passive Other
Frame Window Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
N2 Retry Counter . . . . . . . . . . . . . . . . . . . . . . . . . . . . .150
T1 Ack Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19000
T2 Ack Delay Timer . . . . . . . . . . . . . . . . . . . . . . . . . . .20000
T4 Idle Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50000
