AI296 Version 9.8x User’s Guide
IP Over X.25 Subnet Configuration: Remote Settings
5-7
This example displays Remote IP Address for this Subnet set to 93.67.158.56 .
Remote X.121 Address
Description
This menu item configures the IXE remote X.121 address. Each IXE connection must
have a unique local/remote X.121 address pair. This means there cannot be two
separate IXE connections in the same AI296 with the same local X.121 address and
the same remote X.121 address.
Note: X.121 addresses are assigned per link on AI296, not per SVC.
Menu Item Type
Data
Configuration in the AI198 Menu System
1. Access Menu 4.2.11.13. This menu displays a list of all the configured IP over
X.25 subnets.
2. From Menu 4.2.11.13, enter a value ( 02 through 11 ) associated with the IP over
X.25 subnet to be configure. Menu 4.2.11.13.1 appears.
3. For 05 Remote X121 address , enter 5, and the remote address value. Maximum
length is 15 characters.
This example displays 05 Remote X121 address set to 6505550043 .
IP Over X.25 Subnet Edit Menu
Local IP Address for this Subnet . . . . . . . . . ............... 0.0.0.0
Local IP Mask for this Subnet . . . . . . . . . . . ....... 255.255.255.252
Local X.25 link number . . . . . . . . . . . . . . . . . . . . . 0
Remote IP Address for this Subnet . . . . . . . . . .......... 93.67.158.56
>5,6505550043
Menu 4.2.11.13.1
01 Local IP address for this subnet-----------------------------000.000.000.000
02 Local IP Mask for this subnet--------------------------------255.255.255.252
03 Local X.25 link number----------------------------------------------------01
04 Remote IP address for this subnet----------------------------036.082.234.054
05 Remote X121 address------------------------------------------ 6505550043
