AI296 Version 9.8x User’s Guide
Link Configuration: General Link Properties Configuration
6-26
z V.35 —Data transmission standard for a trunk interface between a network access
device and a packet network.
Menu Item Type
Toggle
Link Type Availability
Async, AsyncPPP, HDLC-Bridge, MLT, SyncPPP, and X.25
Configuration in the AI198 Menu System
1. Access Menu 4.2.11.12.
2. For Hardware Interface , enter the associated item number to select RS232 , RS530 , or
V.35 . The default is RS232 .
This asynchronous link example displays 15*Hardware Interface set to V.35 .
Configuration in the AI296 Local Menu System
1. Access the Link Menu.
2. For Interface Type , select RS-232 , RS-530 , or V.35 .
This example displays Interface Type set to V.35 .
>15
Menu 4.2.11.12
01 Link Number (1-16)--------------------------------------------------------01
02*Link Type (Async, X25, HDLC, SyncPPP, AsyncPPP, MLT)---------------- Async
03 Link Description------------------------------ Async link 1
04*Link state (Enabled, Disabled)-------------------------------------- Enabled
05+Port speed------------------------------------------------------------- 9600
06*Port Data Bits (7, 8)------------------------------------------------------8
07*Port Stop Bits (1, 2)------------------------------------------------------1
08*Port Parity (None, Odd, Even)-------------------------------------------None
09*Flow Control (None, XonXoff)----------------------------------------- None
10 Xon Repeat interval (0 - 120s with 0 = no repeat)------------------------000
11+Connect Options
12+Disconnect Options
13+RTS/DTR Lead Control Options
14+Modem Options
15*Hardware Interface (RS232,RS530,V.35)-----------------------------------V.35
Async Link Menu
Link to configure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Link state . . . . . . . . . . . . . . . . . . . . . . . . . . Up [Down]
Link Type . . [Async] X.25 HDLC-Bridge SyncPPP AsyncPPP MLT
Interface Type . . . . . . . . . . . . . . . . . RS-232 RS-530 [V.35]
