AI296 Version 9.8x User’s Guide
Link Configuration: Disconnect Options Configuration
6-22
This example displays
07 Disconnect string
set to
newString<33>
.
Configuration in the AI296 Local Menu System
1. Access the Async Link Menu.
2. Select
Disconnect Options Menu
. The Disconnect Options Menu appears.
3. For
Disconnect String
, enter the disconnect string.
This example displays
Disconnect String
set to
newString<33>
.
>7,newString<33>
Menu 4.2.11.12.12
01 Disconnect when DSR off--------------------------------------------------N/A
02*Disconnect when DCD off-------------------------------------------------- ON
03*Disconnect when a break character is received----------------------------OFF
04 Disconnect inactivity timer (0 - 32767 s, 0 = disabled)----------------00000
05*Inactivity Timer enabled when link receives call-------------------------OFF
06*Inactivity Timer resets on incoming characters from destination---------- ON
07 Disconnect string----------------------------------newString<33>
Disconnect Options Menu
Link being configured . . . . . . . . . . . . . . . . . . . . . . . . . 3
Disconnect when DCD is off . . . . . . . . . . . . . . . . . . . [On] Off
Disconnect when a Break character is received . . . . . . . . . On [Off]
Disconnect inactivity timer (0 - 32767s, 0 = disabled) . . . . . . . . . .. 367
Inactivity Timer enabled when link receives call . . . . . . . . [On] Off
Inactivity Timer resets on incoming characters from destination On [Off]
Disconnect String . . . . . . . . . . .............. newString<33>
